Right Angle Index Drives convert a uniform input motion into an intermittent output motion. The intermittent output motion is transmitted through our induction-hardened, precision-machined globoidal cam.
Right Angle Indexers are ideal for high speed, high accuracy applications. These indexers convert a uniform input motion into an intermittent right angle output motion. Both the TG and TX Series are driven by flame hardened cams and have a robust design for high-stress environments. TG and TX Series indexers are offered in a fixed station configuration or as a 100% flexible turntable with a servo motor or standard AC brake motor with encoder.
Key Features and Benefits
- Great for high speed applications
- Clockwise, counter clockwise or oscillating movement
- Cam profiles allow for smooth acceleration and deceleration
- Advantages for design engineers and special machine builders
- Accuracies of up to +/- 0.023mm (0.0009”)
- Housing machined on all sides. Suitable for use in any mounting position required
- Mounting holes identical on top and bottom
- Smooth index angles and extended dwell enable continuous use
- Right Angle design enables up to 1000 cycles per minute
- Simultaneously rotating input shaft extension.
- Optional synchronization of other mechanical modules
Technical Benefits for Users
- High speeds possible
- Can have dwell angle larger then index angle
- Extremely reliable with long service lives
- High efficiency mechanical components require less input power
- Flame-hardened cams and cam followers
- Internal components immersed in oil bath
- Low profile housing for seamless integration
Options
- Choice of drive
- Reinforced output flange bearing for higher tilting moment
- Optional friction clutch on drive
- Dwell and index angle can be tailored to requirements
- All sizes also available as programmable flex indexers
- Custom specified color at no extra charge
