How to Choose the Best Gearbox for Your Servo Motor

There are many specialized components that serve specific functions in a modern motion control system. There are electronic pieces, such as the main control computer and motion controllers, which serve as the “brains” of the entire system. There are also mechanical components, such as motors, servos, and linear actuators. One component that can be overlooked sometimes, though, is the gearbox on a servo motor.

What Is A Servo?

A servo or servo motor, at its simplest, is a self-contained electromechanical device that allows for powerful and precise positioning control. Servo motors usually consist of at least an electric motor, a gearbox, a potentiometer, a small control board, and an output shaft. The servo’s controller board receives control data from an outside motion controller. Depending on the degree of motion required, the servo’s controller board instructs the servo’s motor to rotate a certain amount, which results in a commensurate rotation of the output shaft. When the potentiometer detects that the output shaft has rotated the specified amount, it sends a signal to the controller board, which stops the motor and holds the servo at that particular location.

What Types of Servo Are There?

Servos come in a few different configurations, depending on the type of motor used or on the desired output of motion. Servos that use DC motors tend to be a bit quicker than those that use AC motors. However, servos using AC motors can be a bit more accurate and durable than servos using DC motors. In a positional rotation servo, the output shaft can rotate up to 180 degrees. In a continuous rotation servo, the output shaft can continually rotate in a direction for as long as instructed to do so by the motion controller. Linear servos are built to provide side-to-side or back-to-front motion, vs. rotational motion as seen in other servo types.

Certified Motion Control Professional Program

Strengthen Your Skills and Enhance Your Career

Motion control is ubiquitous to automation. A3 offers the fundamental knowledge that benefits everyone working with motion control, motors and automation technologies. The program is designed to ensure professionals have the knowledge they need to advance their careers and benefit their businesses.

Become a Certified Motion Control Professional (CMCP) and join the elite group of system integrators, machine builders, manufacturers, end-users and others recognized in the industry for their professional knowledge and expertise.

Become Certified

What Are the Factors in Choosing A Servo Gearbox?

As compared to other types of gearboxes, those used in servos are fairly unique due to the specific demands placed on them. A servo gearbox needs to deal with high input speeds, have a wide operating range, provide adequate torque for the application, be robust enough to handle continuous and repetitive use, and have low gear backlash. The specific type of gearbox to use depends on the application and space requirements. Common servo gearbox types include:

• Planetary: for high system rigidity, compactness, and high torque
• Spiral Bevel: for larger sizes, better versatility, and higher efficiency
• Hybrid: for applications requiring the best features of both planetary and spiral bevel gearboxes
• Bevel Helical: for reduced size footprint and space efficiency
