PROlinetest | PROFINET Cable Tester

The PROlinetest is a portable cable certification tool designed for validating PROFINET network installations during commissioning and maintenance. This handheld tester verifies that cable installations meet PROFINET performance specifications, identifies wiring errors, and generates compliance reports that document network readiness. By certifying cable quality before production starts, the PROlinetest prevents network failures caused by substandard installations and ensures reliable communication from day one.

Key Features
Automated cable certification that tests PROFINET installations against official specifications including impedance, attenuation, return loss, and propagation delay. The tester compares measured values against PROFINET requirements and provides pass/fail results with detailed performance metrics.

Comprehensive wiring verification that identifies crossed pairs, reversed pairs, split pairs, and other installation errors that could cause intermittent communication failures. The tester displays exact pinout configurations and highlights any deviations from standard wiring patterns.

Cable length measurement using Time Domain Reflectometry (TDR) technology to accurately determine installed cable lengths. This feature helps verify that cable runs stay within PROFINET distance limitations and identifies the exact location of cable faults or breaks.

Signal quality analysis that measures critical electrical parameters affecting PROFINET performance. Engineers can identify marginal installations that might pass basic connectivity tests but fail under production conditions with high traffic loads.

Report generation with detailed test results that can be saved and printed for documentation purposes. These reports provide verifiable proof that cable installations meet specifications, supporting quality assurance requirements and customer acceptance criteria.

Onboard result storage that maintains a history of cable tests for comparison and trend analysis. This feature enables systematic verification that all network segments have been properly tested and certified before commissioning.

Rugged portable design built for industrial environments with protective housing and intuitive operation. The tester includes an integrated display for immediate result viewing and clear LED indicators for quick pass/fail assessment.

Common Applications
New installation commissioning where every cable run must be verified before energizing the network. Systematic testing during construction ensures that problems are identified and corrected before equipment installation, avoiding costly rework after machinery is in place.

Troubleshooting intermittent communication issues that suggest marginal cable performance. While the tester is optimized for proactive certification, it can also validate cable integrity when investigating network problems.

Acceptance testing for contractor-installed cabling systems. Documented test results provide objective evidence that installations meet specifications, protecting against disputes over cable quality and workmanship.

Preventive maintenance programs that periodically verify cable condition in harsh environments. Regular testing can identify developing problems like connector corrosion or cable damage before they cause production interruptions.

Technical Specifications
-PROFINET cable testing with support for Category 5e, Category 6, and Category 6A installations. Compatible with both copper and fiber optic PROFINET networks.
-Test parameters include wire mapping, length measurement, impedance, attenuation, return loss, NEXT (Near-End Crosstalk), and propagation delay.
-Measurement range: up to 100 meters for copper cables with accuracy of ±2% ±0.3 meters.
-Display: High-resolution color screen for detailed result viewing and analysis.
-Power supply: Rechargeable battery with AC adapter for continuous operation during large commissioning projects.
-Operating temperature: -10°C to +50°C for use in industrial environments.

The PROlinetest ensures PROFINET networks start production with certified cable infrastructure, eliminating a major source of communication failures and reducing commissioning time through systematic validation.
