> 5MP 12mm C-Mount Lens Adjustable Aperture
Model: CIL522-F1.4-CMANIR
The CIL522 is a fast 12mm C-Mount lens for up to 5MP 2/3" sensors with 3.45um pixel pitch. The aperture is adjustable from F/1.4 to F/16 and the lens has a minimum working distance of 100mm.
12mm C-Mount Lens 2/3" 5MP
The CIL522 is a fast 12mm C-Mount lens for up to 5MP 2/3" sensors with 3.45um pixel pitch. The aperture is adjustable from F/1.4 to F/16 and the lens has a minimum working distance of 100mm.
5MP-8MP Resolution: Suitable for 3.45um pixel pitch at F/1.4 and 2.74um at F/2.8
Low F#: An fast maximum F# of F/1.4 for demanding high speed machine vision applications.
| Lens Parameter | Specification |
|---|---|
| Part Number | CIL522 |
| Format Type | 2/3" |
| EFL | 12mm |
| F# | CMA: 1.4 - 16 Adjustabl |
| Resolution | 5MP (3.45um) |
| Field of View | 67° @ 11mm Calculate FoV and Angular Resolution |
| Image Circle | 11mm+ |
| Distortion | -0.4% from Rectilinear |
| Weight | 60g |
| Filter | M27x0.5 |
| Working Distance | 150mm~infinity |
| Construction | All Glass |
