The CIL554 is a 25 mm C-Mount lens for up to 25MP 1.2" sensor format type with pixel pitch
25mm C-Mount Lens 1.2" 25MP
The CIL554 is a 25 mm C-Mount lens for up to 25MP 1.2" sensor format type with pixel pitch of 2.74um such as IMX541. The aperture of F/2.8 is adjustable to F/16.
25MP Resolution: Suitable for 2.74um pixel pitch sensors
Adjustable Aperture: An F/2.6-F/16 adjustable aperture allows for optimized performance.
| Lens Parameter | Specification |
|---|---|
| Part Number | CIL554 |
| Format Type | 1.2" |
| EFL | 25mm |
| F# | 2.6 - 16 Adjustable |
| Resolution | 25MP (2.74um) |
| Field of View | 52° @ 19.4mm Calculate FoV and Angular Resolution |
| Image Circle | 19.4mm |
| Distortion | -0.09% from Rectilinear |
| Weight | 78g |
| Filter | M30.5x0.5 |
| Working Distance | 200mm~infinity |
| Construction | All Glass |
