1.1 inch 180 Degree FoV 5mm IR-Corrected C-Mount Fisheye Lens
Model: CIL505-F2.2-CMANIR
The CIL505 is a 5mm C-Mount Fisheye Lens which provides 180° FoV at 14.2mm image circle.
180°@14.2mm C-Mount Fisheye Lens
The CIL505 is a 4.9mm C-Mount Fisheye Lens which provides 180° FoV at 14.2mm image circle. This IP67-rated fisheye lens is suitable for sensors with 3.45um pixel pitch or smaller.
IR Corrected: IR Corrected (3.45um pixel) for surveillance applications
IP67: IP67 rated for dust and water resistance to ensure your camera can withstand the elements.
F-θ distortion: IP67 rated for dust and water resistance to ensure your camera can withstand the elements.
| Lens Parameter | Specification |
|---|---|
| Part Number | CIL505 |
| Format Type | Up to APSC |
| EFL | 4.9mm |
| F# | 2.2 Fixed |
| Resolution | 12MP+ |
| Field of View | 180° @ 14.2mm image circle |
| Image Circle | 14.2mm |
| Distortion | -1% F-Θ |
| Weight | 70g |
| IR Cut-Off Filter | No |
| Construction | All Glass, Metal |
