1/1.8" 16MP+ 4mm M12 Lens for up to 1/2" Sensors | CIL039
Model: CIL039-F2.8-M12IR, CIL039-F2.8-M12NIR
The CIL039 is a 3.9mm no-distortion M12 lens which provides a 77° Horizontal Field of View on a 1/2.3" sensor. The lens provides a wide-angle field of view suitable for computer vision applications.
Lens Parameter Performance Detail
Part Number CIL039
Format Type 1/1.8"
EFL 3.9mm
F# 2.8 Fixed
Resolution 16MP+
Field of View 77° @ 6.2mm
Calculate using our FoV Calculator
Image Circle 8.7mm
Distortion <0.5% TV
Weight 7.0g
Construction Hybrid Glass/Plastic with AL6061 Barrel
