1mm Fisheye M12 Lens
Model: CIL208-F2.2-M12A650, CIL208-F2.2-M12ANIR
The CIL208 is a 5MP 200° M12 fisheye lens with a 2.9mm image circle.
200°@2.9mm Fisheye M12 Lens
The CIL208 is a 5MP 200° M12 fisheye lens with a 2.9mm image circle. The ultra small form factor makes this lens great for doorbell and low profile camera systems.
>200° FoV: Maximize your camera's viewing angle with a 2.9mm image circle.
Tiny Form Factor: 12.9mm TTL with 5MP+ resolution for small 1/3" applications.
| Lens Parameter | Performance Detail |
|---|---|
| Part Number | CIL208 |
| Format Type | 1/4" to 1/3" |
| EFL | 0.9mm |
| F# | 2.2 Fixed |
| Resolution | 5MP |
| Field of View | 200° @ 2.9mm image circle Calculate for your sensor using our M12 Lens Calculator |
| Image Circle | 2.9mm |
| Distortion | -6% F-Θ |
| Weight | 3.3g |
| IR Cut-Off Filter | P/N With: CIL208-F2.2-M12A650 P/N Without: CIL208-F2.2-M12ANIR |
| Construction | All-glass Optical Design PC Cap and AL6061 Barrel |
