Micro850 Training System: VFD, Motion, and Analog Integration

Ready to bridge the gap between software simulation and real-world troubleshooting?

Theory and software models only go so far. Most training labs rely on artificial setups that just don't prepare your team for the realities of a live industrial control panel. That is why we built this training system. It uses the exact industrial components your technicians encounter every day in manufacturing plants, commercial facilities, and automated systems.

We focus on a hands-on approach that builds true troubleshooting confidence, giving your team the practical experience they need to keep your lines running and reduce unplanned downtime.

Tailored to Your Training Needs

Whether you are introducing basic control concepts or mastering advanced automation, you can choose the tier that fits your team:

• Level 1: Core Skills: Features a base industrial Micro850 PLC, a PowerFlex 525 VFD, a 3-phase AC induction motor, discrete/analog I/O, and real push buttons, selector switches, and pilot lights. It is fully 120VAC wall-powered and completely portable.

• Level 2: Smart Factory: Adds advanced sensing capabilities to the core system, including an IO-Link laser distance sensor, motor encoder for real-time PID loop tuning, and discrete inductive and capacitive proximity sensors for material differentiation and predictive maintenance.

• Level 3: Advanced Systems: Introduces high-level mechanics with a Yamaha linear actuator, a 2-axis pneumatic pick-and-place system, a professional pneumatic gripper, digital flow monitoring for energy tracking, and an authentic industrial air preparation unit with a Lockout/Tagout (LOTO) valve.

A Deep Dive Into Industrial Skills

This system isn't just about turning components on and off; it delivers a complete educational curriculum covering:

• PLC Programming & Architecture: Go beyond the basics with downloading, uploading, tag management, and logic sequencing using Ladder (LD), Function Block (FBD), and Structured Text (ST).

• Real Industrial Wiring: No banana plugs here. Technicians work with real industrial wire and terminal screw terminations, practice multimeter troubleshooting, and learn to accurately read electrical schematics.

• Drives, Networking & Motion: Configure variable frequency drives, implement PID loop controls for motor speed, establish solid PC-to-PLC communication, and program precise motion profiles like absolute and incremental moves.

Built for the Modern Workforce

If you are looking to fast-track your maintenance technicians, mechatronics students, or automation engineers, this portable hardware provides a fast, measurable return on your training investment by turning classroom theory into practical, shop-floor capability.
