5069 Compact GuardLogix 5380 Training System: VFD & Motion Integration

Ready to bring high-performance safety and automation training to your team?

Safety is the core of modern machine design, and hardware simulation is the only way to truly build troubleshooting confidence. This 5069 Compact GuardLogix 5380 training system bridges the gap by using authentic, plant-floor industrial components instead of software models.

By utilizing an Industrial Safety PLC, this setup covers both standard CompactLogix logic and specialized safety functions. It provides a hands-on, practical approach that gives technicians and engineers the real experience needed to confidently maintain machinery, optimize automated lines, and minimize unplanned downtime.

Tailor Your Benchtop Lab

Choose the level of complexity that aligns with your facility's training targets:

• Level 1: Core Skills: Builds a foundation with a 5069 Compact GuardLogix controller, a PowerFlex 525 VFD, a 3-phase AC induction motor, discrete/analog I/O, a red mushroom stop button, and real industrial switches. The entire unit is completely portable and powered by standard 120VAC wall outlets.

• Level 2: Smart Factory: Takes the core skills system into the digital transition by adding advanced sensing. This tier integrates an IO-Link laser distance sensor, a motor encoder for real-time PID loop tuning, and inductive and capacitive proximity sensors for material differentiation and predictive maintenance diagnostics.

• Level 3: Advanced Systems: Brings in mechanical motion and fluid power automation. This level includes a Yamaha linear actuator, a 2-axis pneumatic pick-and-place mechanism with a professional pneumatic gripper, digital air flow tracking for energy monitoring, and an authentic industrial air prep station with a Lockout/Tagout (LOTO) valve.

Deep Industrial Curriculum

This system goes beyond basic button-pushing to deliver a complete curriculum in high-demand technical skills:

• Safety & Standard PLC Logic: Learn how to lock and unlock safety controllers, manage controller safety signatures, map standard vs. safety tags, and handle tag-based addressing inside Studio 5000 using Ladder (LD), Function Block (FBD), and Structured Text (ST).

• Real Industrial Wiring: There are no banana plugs here. Technicians work with real industrial wire and terminal screw terminations, perform active multimeter diagnostics, and learn to trace out industrial schematics.

• Drives, Networking & Motion Control: Configure and protect variable frequency drives, implement PID control loop tuning, program smooth Yamaha motion profiles (including homing, jogging, and absolute moves), and set up EtherNet/IP Device Level Rings (DLR).

Built for the Modern Automation Professional

Designed for maintenance technicians, safety engineers, and automation professionals looking to cross-train, this rugged, portable setup turns classroom concepts into immediate capabilities on the plant floor.
