Technosoft is a leading gloval manufacturer of motion control products, offering intelligent OEM drive solutions for universal control of AC servo, Stepper, and CD Motors. All products are fully programmable, enabling distributed control via RS232, RS485, CANopen, and EtherCAT networks. A full compliment of software tools, including EasyMotion Studio and host level libraries are offered to speed development of motion and machine control applications.
Product filed under:
AC Servo Drives, Adjustable Speed Drives, and DC Servo Drives AC Servo Drives, Adjustable Speed Drives, DC Servo Drives, Drives & Amplifiers, Motors & Drives, and Stepper Drives
See More
iPOS3602 MX Intelligent Drive (75 W, CANopen / EtherCAT)
- Standard PCIe 4x mating connectors
- Sinusoidal (FOC) or trapezoidal (Hall-based) control of brushless motors
- Open-loop or closed-loop control of 2-phase and 3-phase steppers
- Various modes of operation: torque, speed or position control; position or speed profiles; reference: external analog, or sent via a communication bus
- TML instruction set for the definition and execution of motion sequences
- Standalone operation with stored motion sequences
- RS-232 serial communication
- CAN-Bus 2.0B up to 1 Mbit/s, or CANopen
- EtherCAT communication via additional extension module (optional)
- Digital and analog I/Os:
- 5 digital inputs: 5-36 V, NPN (Enable, 2 limit switches and 2 general-purpose ones)
- 4 digital outputs: 5-36 V, 0.5 A, NPN open-collector (Ready, Error, 2 general-purpose outputs)
- 2 analog inputs: 12-bit, 0-5 V: Reference, Feedback or general-purpose
- Feedback devices supported:
- Incremental quad encoder (single-ended, open collector and differential)
- Analog sine/cosine incremental encoder (differential 1 Vpp)
- Digital and linear Hall sensors
- Easy configuration and programming with EasyMotion Studio software platform
- Protection to over-current, short-circuit, earth fault, over- / under-voltage, I2t, control error
