SIMOTICS S-1FK7 Synchronous Servo Motors
Model: SIMOTICS S-1FK7
.png)
The SIMOTICS S-1FK7 motors are permanent magnet synchronous motors with high overload capability and an integrated encoder system for speed and position control depending upon needs of the motion control application. The motors are available with various configurable options including encoder type, holding brake, shaft extension, and planetary gearbox. When combined with the SINAMICS S120 drive system the encoder is available with an electronic nameplate (DRIVE-CLiQ interface) which enables quick machine configuration due to automatic load of motor data into drive system and reduction of hardware components. Continuous rated power is available up to 11 Hp @ 3,000 rpm.
Benefits
- Three rotor inertia categories of Compact, High Dynamic and High Inertia to assist in optimized control of load
- Encoder system available as incremental, absolute multiturn and resolver with multiple levels of resolution according to budget and application requirements
- Raised reliability of motor via decoupled encoder which insulates encoder from thermal and vibration stresses
- Electronic nameplate for quick machine startup
