SIG-400 (Source Imaging Goniometer®)

The SIG-400 (Source Imaging Goniometer®, Gen. 4) is a fully automated, computer-controlled goniometric system designed specifically to meet the needs of LED researchers, developers, manufacturers, and users for LED die and device characterization.

The SIG-400 uses a ProMetric® I Series Imaging Colorimeter to generate highly accurate near-field models for LEDs; this data can be used directly to investigate the performance of the LED or it can be exported, via Radiant Vision Systems ProSource® Software, for use in all major optical design software packages.

The SIG-400 system consists of a ProMetric Imaging Colorimeter, a goniometric assembly for positioning the imaging colorimeter and the light source relative to each other, and control and analysis software. The SIG-400 captures images of the light source from multiple angles, building a three-dimensional spatial image of the color and luminance output of the device. These measurements are aggregated into a Radiant Source Model™ (RSM) format, which is a detailed, industry-standard model for light source near-field data representation. RSMs contain all of the measurement information, including the image data, so the measurement results can be reviewed in detail at any time. RSMs are used to compare the optical properties and design of various LEDs and to generate input to optical design software for use in luminaire and optical system design.

Applying Radiant's ProSource® Software to the RSM, ray sets containing an arbitrary number of rays can be generated for export to other optical and illumination system design software packages such as ASAP®, FRED®, LightTools®, LucidShape®, Photopia™, IES TM-25, Opticad®, OSLO®, SimuLux®, SPEOS®, TracePro®, and OpticStudio™ (ZEMAX), as well as general file formats. Because the RSM is a complete description of the light source, it can be used to generate and regenerate ray sets at will.
