ProMetric® Y Imaging Photometer

Fast, small-format photometers optimized for display test and cosmetic inspection in production environments.

ProMetric Y is a family of award-winning, high-performance imaging photometers from Radiant Vision Systems. ProMetric Y is designed for high-volume production testing of flat panel displays, phones, tablets, notebooks, keyboards, backlit components, and lighting products, including AR/VR devices and automotive head-up displays. The ProMetric Y delivers reliable test results and analysis to improve quality and control costs:

• Faster measurements deliver shorter cycle times
• Objective quantification is superior to subjective human inspection
• Faster, more accurate test analysis improves yield

Each ProMetric Y Imaging Photometer employs a scientific-grade image sensor optimized for low image noise to provide accurate, repeatable measurements. ProMetric cameras maximize resolution and dynamic range to ensure imaging performance. ProMetric Y supports high-speed USB and Ethernet communications.

Available resolutions:

• 2-megapixel (1600 x 1200)
• 29-megapixel (6576 x 4384)
• 43-megapixel (8040 x 5360)
• 45-megapixel (8192 x 5460)
• 61-megapixel (9568 x 6380)

Key Features and Highlights

• High Speed: Minimum measurement time (photopic) as fast as 0.2 seconds
• High-resolution sensor options
• Available in photometric and radiometric models
• Multiple lens options: 20 mm, 35 mm, 50 mm, 100 mm macro, and 200 mm
• ProMetric control and analysis software is standard. TrueTest™ Automated Visual Inspection Software and other software modules optional.

ProMetric software includes API support, and provides complete measurement control and Point of Interest/Region of Interest functionality. In addition, the ProMetric Y imaging photometers are backed by the industry's best product warranty, including direct access to the Radiant Vision Systems technical support team to maximize the utility of your application.
