Robotic Servo Belt Stand, Floor-standing with Compliant Force Control with a high-torque servo motor.
SFS82 Series
Servo Finishing Stand
The PushCorp SFS82 Servo Finishing Stand combines compliant force control with a high-torque 5.7 hp [4.28 kW] servo motor. This precise force and speed control allows you to achieve unprecedented levels of quality and consistency.
The SFS82 Servo Finishing Stand is designed to enable maximum flexibility for any robotic part-in-hand material removal application. Linear travel compliance and excellent access allow a robot to easily manipulate parts over the belt media and perform the following operations.
- Deburring (parting lines, chamfer)
- Polishing (glass, wood, metal)
If the application will require more torque, the SFS92 is the largest finishing stand in the series. It features a robust set of linear bearings, can apply 215 lbf [956 N], and has 62 lb· ft [84 N·m] continuous stall torque.
The SFS82 Servo Finishing Stand is belt driven by a high-torque servo motor. This drive system has a 2:1 reduction that provides plenty of power at the contact wheels.
FEATURES
- Passive Force Control
- Servo motor amplifier included
- Contact wheel position output
- Accurate media speed control
- 1.6 in [40 mm] linear compliant stroke
- All fittings, fasteners, and threaded holes are METRIC
SPECIFICATIONS
| Model | SFS82 Series |
| Max Applied Force | 115 lbf [511 N] |
| Force Resolution | 1.4 lbs/psi [90.4 N/Bar] |
| Compliant Stroke | 1.6 in [40 mm] |
| Weight | 370 lbs [168 kg] |
| Supply Air | Dry, 5µm Filtered, Non-lubricated, 80 psi [5.5 Bar] max |
| Horsepower | 5.7 hp [4.28 kW] |
| Continuous Stall Torque | 14.7 lb· ft [20 N·m] |
| Output Shaft Speed | 0-2000 rpm (Reversible) |
