DCO-1000-ASL Series
DIN-Rail Fanless Embedded Computer

DCO-1000-ASL with fanless, compact and DIN-Rail mounted design features the Intel Atom x7433RE processor, ensuring powerful performance and energy efficiency. Ideal for space-constrained installations requiring high reliability, the DCO-1000-ASL excels in advanced data processing at the edge, making it essential for successful IoT implementations in demanding industrial settings.

• Small Form Factor with DIN-Rail Mounting
• Intel® Atom® Processor x7433RE
• Doubling Performance with DDR5 Memory
• Support Up to 4x 2.5 GbE LAN
• OOB (Out-of-Band) Module for Remote Management
• Industrial-Grade Design
• World-Class Certification: UL 61010, FCC, CE

Small Form Factor Design & DIN-Rail Mounting

The DCO-1000-ASL excels in the industrial computer market with its ultra-small form factor and DIN-Rail mounting. This configuration optimizes space while ensuring full industrial PC functionality:

• Ultra-Compact Design: Maximizes space efficiency in tight areas.
• DIN-Rail Mounting: Enables quick, secure installations and easy maintenance.

Intel® Atom® x7433RE Processor

The DCO-1000-ASL is equipped with the Intel® Atom® x7433RE processor, which provides robust computing power and enhanced energy efficiency, making it ideal for demanding industrial IoT applications.

Blazing-Fast DDR5 Integration

DDR5 memory significantly increases transfer speeds compared to its predecessor, offering enhanced performance, lower latency, and improved power efficiency.

Balanced I/O Configuration

The DCO-1000-ASL offers a wide range of I/O connections within its ultra-compact design. Its integrated I/O ensures smooth compatibility, integration, and performance with various IoT devices and sensors.

• USB 3.2 Gen 2 & USB 2.0, enables versatile peripheral connections
• 4x 2.4 GbE Ethernet for highspeed network
• 2x Serial Port, robust communication with a variety of legacy equipment
• 2x 4K DisplayPort allow to monitor complex processes in ultra-high definition

M.2 Expansions & Wireless Connectivity

Designed to meet the demanding needs of modern industrial environments, DCO-1000-ASL is equipped with advanced M.2 slots to cater to various expansion needs, ensuring versatile connectivity and storage options.

• 1x M.2 B Key (3042/3052, PCIe x2, support NVMe Storage), default 128GB
• 1x M.2 B Key (3042/3052, USB 3.2 Gen2 & USB2.0, support 4G/5G Module)
• 1x M.2 E key (2230, PCIe x1 & USB2.0, support Wifi/Bluetooth)

Enable Remote Access Through OOB Management Module

The DCO-1000-ASL features an Out-of-Band (OOB) remote management module, which offers enhanced control and monitoring capabilities.

• Manage devices from any location, reducing the need for onsite visits.
• Secure access to device management, even if the main OS is down.
• Quickly identify and resolve issues remotely, minimizing downtime.
• Deploy updates and software fixes remotely and seamlessly.

Built Rugged. Built Ready

DCO-1000-ASL is engineered to excel in extreme conditions, ensuring reliable performance in diverse environments. This robust system boasts a range of features designed for high durability and operational resilience:

• Extended Operating Temperature: -40°C to 55°C
• MIL-STD-810G Shock & Vibration: 20G/5Grms
• Wide Power Input: 9~36VDC
• Power Protection: OCP, OVP, RPP

World-Class Safety Certifications

At Premio, we pride ourselves in providing competent edge computing solutions that deliver reliable performance while deployed in challenging industrial environments. DCO-1000-ASL has achieved UL 61010-1 which is an international standard for electrical equipment for measurement, control, and laboratory use, and has been rigorously tested and validated for safety standards compliance.

• UL 61010-1
• FCC
• CE
