ACO-6000-CML | EN50155 IN-VEHICLE COMPUTER | 10^th GEN INTEL® CORE™ AND INTEL® XEON® W PROCESSOR

The ACO-6000-CML Series in-vehicle computers are validated under strict certifications, including E-Mark, CE, FCC, and EMC Conformity with EN50155 & EN50121-3-2 railway standards. Intelligent transportation systems have become even more significant as transformative technologies process data for machine learning and intelligence at the edge. As a result, many in-vehicle applications require reliable, high-performance computers to handle data processing from a variety of sensors and IoT devices for low-latency communication.

• Intel® 10th Gen Core LGA1200 Socket with W480E chipset
• Intel® Xeon-W processors with ECC Memory Support
• EMC Conformity with EN50155 & EN50121-3-2
• Wide Power Supply Input 9-48VDC and 48-110VDC
• Support up to 18x LAN (16x M12/RJ45 GbE/PoE + 4x RJ45 GbE Ports)
• Built-in CAN Bus Transportation Protocol
• Power Ignition Management
• 5G Ready

10th Gen Intel® Core™ And Intel® Xeon® W Processors

The ACO-6000-CML In-Vehicle Computer leverages rich performance enhancements provided by W480E Chipset to support 10th Gen Intel CML S Processors or optional Intel XEON W-1290TE processors with ECC memory support for server-grade performance. The processors ensure reliable and powerful performance, capable of handling numerous sensors and IoT devices amid deployments.

• 10th Gen Intel® Core™ (35W TDP)
  • Up to ten hyperthreading cores
  • Intel® UHD Graphics 630
• Intel® Xeon® W-1290TE (35W TDP)
  • Up to ten hyperthreading cores
  • Supports Error Correction Code (ECC) memory

EDGEBoost I/O - Modular Daughterboards

A key differentiator of the ACO-6000-CML in-vehicle computer is its I/O scale for its size. The modular design supports scalability up to 4x universal I/O brackets with up to 16x I/O ports. The 16x port expansions can be configured into 16x RJ45, 16x M12, or 16x USB ports, with optional GbE/PoE ports, a key advantage for connecting IoT sensors at the edge. The versatile I/O also supports Dual 10 GbE LAN/PoE and Dual-SIM 5G modules.

Remote And Wireless Connectivity From The Rugged Edge

The ACO-6000-CML Series enables seamless wireless connectivity for remote and mobile edge deployments. It can be configured with Dual-SIM 4G/LTE and Dual-SIM 5G cellular connectivity to provide redundancy amid remote, rugged edge deployments. The in-vehicle computer is also certified to connect and pass data telemetry into the cloud.

• Wi-Fi 6
• Bluetooth 5.0
• Embedded Dual-SIM 4G/LTE cellular
• Modular Dual-SIM 5G cellular
• Cloud Certified Device on Microsoft Azure and Amazon AWS Greengrass

Redundant IoT Data Storage

The ACO-6000-CML in-vehicle computers can be configured with 3x 2.5” SATA SSDs, 1x internal 2.5” SATA SSDs at 9mm height, and 2x external hot-swappable SATA SSDs at 7mm height. The external 2.5” bays permit toolless, hot-swappable replacement of the SATA drives, simplifying service, and capacity upgrades.

• High-Speed NVMe storage
• High-Capacity SATA storage
• Hardware and Software RAID Availalble

Performance Accelerators With PCI Express Slots

The ACO-6000-CML Series can be configured with a PCIe Gen 3.0 slot or an optional PCI slot for various high-speed performance accelerators such as:

• Raid Cards
• Video Capture Cards
• Wireless Network Cards
• I/O Ports Expansion Cards

Higher Voltage For Railway Deployments (48-110VDC)

The EN50155 certification ensures the ACO-6000-CML Series can support 9-48VDC and 48-110VDC of power supply inputs to cover all voltage levels, including the most common 24V, 72V, and 110V in electronic railway and rolling stock equipment. In addition, when a large voltage fluctuation occurs in the system due to a damaged converter or a short circuit, the ACO-6000-CML Series is built with Over Voltage Protection (OVP) and Over Current Protection (OCP) to ensure the system's safety and durability.

Built-In Embedded CAN Bus For Vehicle Telematics

The ACO-6000-CML Series supports a two-channel, two-pin CAN Bus I/O and Protocol embedded on the motherboard. The CAN Bus support allows the computer to leverage vehicle telematics data and provide real-time analytics for intelligent transportation systems, fleet management, process analytics, and system optimization.

Power Ignition Management

The power ignition management feature delays the system shutdown after engine shutoff for a pre-determined, programmable interval to ensure that no data corruption occurs due to a sudden and abrupt shutdown. Configurable for both 12V and 24V systems, this feature ensures that applications close properly, avoiding data loss or corruption.

Built Rugged. Built Ready.

The ACO-6000-CML fanless in-vehicle computers are tested and validated to ensure safe and reliable operation for mission-critical, automotive applications. The fanless in-vehicle computers come with various additional features to process a massive influx of data coming from various sensors and IoT devices while maintaining their reliability amid rugged edge deployments.

• Fanless and cableless architecture industrial PC
• Wide -25°C ~ 70°C operating temperatures
• 50G Shock and 5 Grms Vibration resistance
• Wide Power Supply Input 9-48VDC and 48-110VDC
• Programmable Power Ignition Management
• TPM 2.0 for password protection, device authentication, and cybersecurity
