LA21

The LA21 actuator offers a compact and high-performance solution for applications where installation space is limited – without compromising on power, speed, or precision. With up to 3,500 N force, stroke length up to 800 mm, and speeds up to 85 mm/s, it enables fast and reliable movement where larger actuators simply won’t fit.

Built for harsh environments, the LA21 withstands vibrations, moisture, chemicals, and extreme temperatures. Featuring robust metal gears, a proven housing design, and an integrated brake, it ensures long-lasting reliability and consistent performance.

Key features:

• Compact and clean design
  The three-part motor housing encloses the spindle and components tightly, minimizing space usage. Straight or angled cable options simplify installation in confined areas.
• High performance
  Available in five load categories from 500 N to 3,500 N, with speeds up to 85 mm/s for fast, precise movement. Choose the configuration that best fits your application.
• Reliable under pressure
  Withstands dust, water, and high-pressure cleaning (up to 90°C at 320?bar). Rated up to IP66 during operation and IP69K when idle.
• Flexible built-in options
  Stroke lengths from 50 mm (70 mm for IC versions) up to 800 mm, with multiple mounting options for seamless integration.
• Multiple power options
  Operates on 12 V, 24 V, or 48 V, allowing easy integration into various system architectures.
• Intelligent movement
  Supports integration with intelligent control systems for enhanced positioning and feedback capabilities.

Proven across industries, the LA21 is ideal for agricultural machinery, construction, vehicles, and industrial automation. Wherever space is limited but performance, reliability, and speed are essential, the LA21 delivers a compact, high-quality solution.
