INTEGRATED SANDING SOLUTION FOR TEXTURE-FREE SURFACE TREATMENT OF LARGE SURFACES
The AOK HD is a finely tuned system package based on the Active Compliant Technology (ACT) and orbital sanders optimized for robot use and large surfaces. This integrated complete solution automates the industrial sanding process with individual control of all process parameters: rotation speed, contact force and feed rate. The AOK HD offers the highest process quality from a single source and the system design is compact and light. The eccentric mode can be switched from free-run mode to forced mode and the gimbal unit allows adapting flexibly to the surface. The enormously durable sander is designed for industrial use and delivers twice the output of standard devices, 24 hours a day, 7 days a week.
Surface treatment: Sanding, polishing, cleaning
All materials: Steel, aluminum, titanium, magnesium, carbon, plastic, wood, ceramic, composite materials …
GRINDING PACKAGE SOLUTION FOR INDUSTRY 4.0
- User-friendly industrial package solution
- benefits of the ACT system cooperation• Robot-compatible sander combined with all the
- For all industries and materials
QUICK, FLEXIBLE, SAFE
- High performance and functionally optimized system for immediate integration
- Rapid job modulation directly by the end user
- Optimal functionality, productivity and process reliability
CONTROL OF ALL PROCESS PARAMETERS
- Contact force on the surfaces in an integrated system solution
- Feed rate of the robot
- Rotation speed of the orbital sander
TOP QUALITY
- Precisely even surface appearance thanks to a process-optimized package solution
- No post-processing
- The highest quality level 24 hours a day, 7 days a week
SPECIFICATIONS
| Ordercode | AOK/601 |
| Max. force (push/pull) [N] | 500 |
| Stroke [mm] | 48 |
| Dimensions [mm] | Max. 343 x 299 x 402 Bolt circle ISO 9409-1-80-6-M8 standard flange ø80 |
| Dead weight [kg] | ~ 28 |
| Power supply | • 24 V (DIN-track) • 400 - 480 V AC (frequency inverter) • ø8 mm air supply | Max. 7 bar, 30μm, ISO 8573-1 Kl.3 (oil & water free) • 4 x ø6 mm operated air supply for switching the eccentric mode and to block the gimbal unit | Max. 7 bar, 30μm, ISO 8573-1 Kl.3 (oil & water free) |
| Max. speed [rpm] | 6,800 recommended 5,000 |
| Motor power (S3) [W] | 4,000 |
| Motor peak power (S2) [W] | 5,900 |
| Excentric stroke [mm] | 5 |
| Grinding disc | 3 x 150mm / 6” pad with fast fix |
| Forced eccentric mode | on/off |
| Air consumption [l/min] | 15 – 30 |
| Extraction connection [mm] | ø42 |
| Ambient temperature during operation [°C] | +5 … +45 |
| Protection class | IP65 / if equipped with adequate filters |
