2mm IP67 Fisheye M12 Lens
Model: CIL217-F2.7-M12A650, CIL217-F2.7-M12ANIR
The CIL217 is an IP67 3MP+ 200° M12 fisheye lens with a 5.7mm image circle.
200°@5.7mm IP67 Fisheye M12 Lens
The CIL217 is an IP67 3MP+ 200° M12 fisheye lens with a 5.7mm image circle. This lens is great for small surveillance applications and sensors such as AR0234.
IP67: IP67-rated plus front o-ring flange for exterior applications.
Miniature Size: The 14.9mm TTL makes this lens great for miniature applications.
Unique distortion: Positive F-Θ in the center results in low distortion up to 5mm image circle.
| Lens Parameter | Performance Detail |
|---|---|
| Part Number | CIL217 |
| Format Type | Up to 1/1.5" Circular Fisheye |
| EFL | 1.7mm |
| F# | 2.7 Fixed |
| Resolution | 3MP+ |
| Field of View | 200° @ 5.7mm image circle Calculate for your sensor using our M12 Lens Calculator |
| Image Circle | 5.7mm |
| Distortion | Non-standard distortion. Please see distortion LUT on mechanical drawing. |
| Weight | 4.0g |
| IR Cut-Off Filter | P/N With: CIL217-F2.7-M12A650 P/N Without: CIL217-F2.7-M12ANIR |
| Construction | Hybrid Glass/Plastic, Aluminum |
