Commonlands LLC Product
Member Since 2022
Commonlands offers high-performance cost-effective M12 lenses, C-Mount Lenses, and related accessories. ISO9001 Certified. Volume discounts. Worldwide shipping. Lenses used with Raspberry Pi HQ cameras.
Product filed under:
Optics / Lenses / Filters Optics / Lenses / Filters
F-Theta 2mm Fisheye M12 Lens for up to 1/2.5" sensors with full coverage. The all-glass design and F-theta distortion is ideal for multi-camera stitching.
The CIL292 is a small M12 S Mount Fisheye Lens for up to 1/2.5" sensors with full coverage. The all-glass design and F-theta distortion is ideal for multi-camera stitching.
| Lens Parameter | Performance Detail |
|---|---|
| Part Number | CIL292 |
| Format Type | >=1/2.5" |
| EFL | 2.3mm |
| F# | 2.1 Fixed |
| Resolution | 5MP+ (1.85um) |
| Field of View | 183° @ 7.1mm Calculate for your sensor using our M12 Lens Calculator |
| Image Circle | 7.1mm as designed |
| Distortion | -3% F-θ |
| Weight | 3g |
| IR Cut-Off Filter | P/N With: CIL292-F2.1-M12A650 P/N Without: CIL292-F2.1-M12ANIR |
| Construction | 5G1MG |
| CRA | 18° |
Other Products from Commonlands LLC
1/2.5 inch 18mm M12 Lens Telephoto
The CIL178 is an 18.4mm M12 Lens for up to 2MP 1/2.5" sensors. The short TTL and low F/2.0 make this lens fit into a unique optical design space. Short TTL TTL of 20mm is great for a compact telephoto camera design.
1/2.5 inch Stereographic Compact M12 Lens
The CIL825 is a 2.5mm M12 lens which provides a 115° Diagonal Field of View on 1/3" sensors. This lens has a compact lightweight form factor. A small size for lightweight or hidden applications. Create an image with limited distortion.
