>25MP 16mm C-Mount Lens Adjustable Aperture
Model: CIL553-F2.8-CMANIR
The CIL553 is a 16mm C-Mount lens for up to 25MP 1.2" sensor format type with pixel pitch of 2.74um
16mm C-Mount Lens 1.2" 25MP
The CIL553 is a 16mm C-Mount lens for up to 25MP 1.2" sensor format type with pixel pitch of 2.74um such as IMX540. The aperture of F/2.8 is adjustable to F/16 and the minimum object distance is 125mm. Please note that this lens does not have front filter threads.
<0.09% Distortion: Good for machine vision
25MP 1.2": Sharp images for demanding 2.74um pixel size
Adjustable Aperture: Optimize your Depth of Field
| Lens Parameter | Specification |
|---|---|
| Part Number | CIL553 |
| Format Type | 16mm |
| EFL | 2.8-16 Adjustable |
| F# | 25MP (2.74um) |
| Resolution | 63° @ 19.4mm image circle Calculate for your sensor |
| Image Circle | 19.4mm |
| Distortion | -0.09% from Rectilinear |
| Weight | 128g |
| Filter | None |
| Working Distance (MOD) | 150mm-inf |
| Construction | All Glass |
