1/2.5 inch 6mm IP69K-Rated M12 Lens

Model: CIL061-F1.9-M12B650, CIL061-F1.9-M12B660, CIL061-F1.9-M12BNIR

Commonlands LLC

Request a Quote

The CIL061 is a 6mm M12 lens suitable for up to 3MP 1/2.5" sensors. It's <3% distortion and F/1.8 makes it great for ADAS and computer vision applications on sensors like Sony's IMX290 and AR0234. Great low light performance for

Image of 1/2.5 inch 6mm IP69K-Rated M12 Lens

Lens Parameter Performance Detail

Part Number CIL061

Format Type 1/2.5"

EFL 6.0mm

F# 1.9 Fixed

Resolution 3MP (3.0µm)

Field of View 66° @ 7.0mm

Calculate using our FoV Calculator

Image Circle 7.6mm

Distortion -8% / -5% TV

Weight 5g

Construction All Glass with Aluminum Barrel

Click here for full documentation.

An M12 lens is a miniature lens with 12mm diameter threads. These lenses are also known as S-Mount Lenses or Board Mount Lenses. M12 lenses are used in robotics, surveillance cameras, video conferencing, and internet of things cameras. Types of M12 lenses include fisheye, wide-angle, no-distortion, and telephoto. Our S-Mount lenses range from 1mm to 50mm focal length and 10° to 230° field of view. M12 lenses can also be used with many CS and C Mount cameras.
