3mm M12 Lens Low Distortion

Model: CIL027-F2.8-M12A650, CIL027-F2.8-M12ANIR

Commonlands LLC

Request a Quote

The CIL027 is a 2.7mm wide-angle low-distortion M12 lens which provides a 99° Horizontal Field of View on 1/2.3" sensors. Wide-Angle FoV: Achieve a wide 100° HFoV on 1/2.3" type sensors. Thermal Stability: Optical Resolution suitable for IMX178.

Image of 3mm M12 Lens Low Distortion

Low Distortion 2.7mm M12 Lens

?The CIL027 is a 2.7mm wide-angle low-distortion M12 lens which provides a 99° Horizontal Field of View on 1/2.3" sensors.

Wide-Angle FoV: Achieve a wide 100° HFoV on 1/2.3" type sensors.

Thermal Stability: Optical Resolution which is suitable for the Sony IMX178.

Ingress Protection: Low Distortion Wide-Angle up to 1/1.8" format type.

Lens Parameter Performance Detail

Part Number     CIL027

Format Type      1/2"

EFL                        2.7mm

F#                          2.8 Fixed

Resolution          10MP

Field of View     99° @ 6.2mm

                               Calculate using our FoV Calculator

Image Circle      8.0mm (usable)
                               9.0mm (max)

Distortion           3% TV

Weight                6.2g

Construction     5G2P, AL6061

Click here for full documentation.
An M12 lens is a miniature lens with 12mm diameter threads. These lenses are also known as S-Mount Lenses or Board Mount Lenses. M12 lenses are used in robotics, surveillance cameras, video conferencing, and internet of things cameras. Types of M12 lenses include fisheye, wide-angle, no-distortion, and telephoto. Our S-Mount lenses range from 1mm to 50mm focal length and 10° to 230° field of view. M12 lenses can also be used with many CS and C Mount cameras.
