1/2 inch 12.5mm Telephoto High Resolution M12 Lens

Model: CIL125-F2.4-M12A650, CIL125-F2.4-M12ANIR, CIL125-F3.6-M12A650, CIL125-F3.6-M12ANIR, CIL125-F8.0-M12A650, CIL125-F8.0-M12ANIR

Commonlands LLC

Request a Quote

The CIL125 is a 12.5mm M12 lens for up to 12MP+ 1/2.3" sensors. This telephoto board lens has great MTF, making it suitable for high resolution applications. A cost effective 10MP+ lens for applications requiring high sharpness.

Image of 1/2 inch 12.5mm Telephoto High Resolution M12 Lens

Telephoto 12mm M12 Lens

The CIL125 is a 12.5mm M12 lens for up to 12MP+ 1/2.3" sensors. This telephoto board lens has great MTF, making it suitable for high resolution applications.

High Resolution: A cost effective 10MP+ lens for applications requiring high sharpness.

Lens Parameter Performance Detail

Part Number     CIL125

Format Type      1/2"

EFL                        12.5mm

F#                          2.4, 3.6, or 8.0 Fixed

Resolution          F/2.4: 10MP- 12MP
                               F/3.6: 6-8MP
                               F/8.0: 4-5MP

Field of View     28° @ 6.2mm

                               Calculate using our FoV Calculator

Image Circle      8.2mm+

Distortion           <0.5%

Weight                6.8g

Construction     Hybrid Glass/Plastic

Click here for full documentation.
An M12 lens is a miniature lens with 12mm diameter threads. These lenses are also known as S-Mount Lenses or Board Mount Lenses. M12 lenses are used in robotics, surveillance cameras, video conferencing, and internet of things cameras. Types of M12 lenses include fisheye, wide-angle, no-distortion, and telephoto. Our S-Mount lenses range from 1mm to 50mm focal length and 10° to 230° field of view. M12 lenses can also be used with many CS and C Mount cameras.
