Comau LLC Product
Member Since 2023
Comau offers its global capacity as a manufacturer and systems integrator of complete engineering solutions, robotics and automation products, from product development to the realization of industrial process automation solutions and an entire range of aftermarket support services.
Product filed under:
Articulated, Collaborative, and Robots Articulated, Collaborative, and Robots
Comau MyCo-3-0.59 is the collaborative robot with payload 3kg and reach 590mm designed for quick installation, easy programming, and rapid
MyCo-3-0.59 is the collaborative robot with payload 3kg and reach 590mm
The MyCo family of cobots is designed for quick installation, easy
programming, and rapid redeployment to support faster lead times and
reduce integration complexity Combining collaborative safety features with ergonomic benefits, MyCo
enables humans and robots to work side-by-side, improving employee well-being, optimizing floorspace, and supporting safer, more inclusive
operations. With six lightweight models (3 kg to 15 kg payloads), Comau’s new collaborative robot family delivers a precise, reliable and cost-effective automation solution for companies of all sizes
to know more please visit our website
Technical specifications
| Model | MyCo-3-0.59 |
| Maximum wrist payload | 3 kg |
| Robot weight | 18 kg |
| Maximum horizontal reach | 590 mm |
| Power consumption | 100W “Typical Application” |
| Joint Range | J1, J4, J6 ±360° J2 ±135° J3 ±150° J5 ±147° |
| Joint Speed | “J1–J4 180°/s J5–J6 200°/s” |
| Tool Speed | 2m/s |
| Repeatability | ±0.02mm |
| Degree of Freedom | 6 |
| Dust and Water Protection Class | IP54 (IP66 optional) |
| UL94 Classification | V0 |
| Mounting Position | Floor / Ceiling / Inclined Plane / Wall |
| End I/O Port | Digital input: 3, Digital output: 3, Analog input: 2 |
| Control box I/O port | Digital input: 16, Digital output: 16, Analog input: 2, Analog output: 2 |
| I/O Source | 24V 2A |
| Communication | TCP/IP, ModbusTCP, Profinet (Optional), Ethernet/IP (Optional) |
| Programming | Graphical Programming, Remote calling interface |
| Collaborative Operation | 10 advanced security configuration functions |
| Main Material | Aluminium Alloy |
| Working Temperature | 0-50°C |
| Power Input | 100-240V AC, 50-60Hz |
| Cable | Cable to control box: 5m, Cable to teach pendant: 5m |
