CIS Corporation is a development-oriented manufacturer of cameras for use in various applications. The advanced CIS camera line includes high-performance cameras with CIS original ISP, state-of-the-art “Clairvu engine™” for superb imaging quality and high speed processing. We provide FPGA IP or software license as well as compact size, high-resolution, high-speed cameras. The product design philosophy of CIS is driven by industry requirements and offers products with the most advanced technology.
Product filed under:
Cameras & Smart Cameras and CoaXPress Cameras & Smart Cameras and CoaXPress
5M rosolution, 29×29×55mm small size CoaXPress camera.
Model: VCC-5CXP7M (Monochrome) / VCC-5CXP7R (Color)
5M resolution CoaXPress interface camera with Sony 4th generation image sensor “Pregius S IMX547”. Suitable for FA applications with its compact size, 29x29x55mm, and long distance data transmission capability.
The camera features versatile functions such as global shutter, external trigger, ROI, gain, defective pixels correction, shading correction, gamma correction, 2×2 binning (B/W model only) etc. that enables you to see the object easier as well as contributing inspection efficiency.
[SPEC]
VCC-5CXP7M (Monochrome) / VCC-5CXP7R (Color)
I/F: CXP6×1lane, CXP3×1lane
Sensor: 1/1.8type Sony Pregius S IMX547 CMOS image sensor
Effective pixel number: 2472(H)×2064(V)
Frame rate: 101fps (8bit)
Lens mount: C mount
Dimensions: 29×29×55mm
Features: Global shutter, Connector:BNC, External trigger, Long distance transmission, ROI, Defective pixel correction, Shading correction, Gain, Gamma correction, 2×2 binning (B/W model only) etc.
For further specifications, please contact our Sales division.
