Since 1993, BitFlow has been developing industrial frame grabbers and software specializing in interfacing to cameras with high data/frame rates; and running in applications where every CPU cycle is precious. We currently offer CXP, CL, and Differential frame grabbers.
Product filed under:
Control Components, Controls, and I/O Control Components, Controls, and I/O
- 36 inputs, 36 outputs
- 12 TTL inputs, 12 TTL outputs
- 12 differential inputs, 12 differential outputs
- 8 Opto-isolated input, 8 Opto-isolated outputs
- 4 high voltage inputs (12 to 24 V), 4 high voltage outputs (Open Collector - 3.3 to 24V)
- Input level can be read by software
- Inputs can be routed to the acquisition engine, Timing Sequencer trigger, camera, outputs
- Outputs can be static (software controlled), dynamic (from the Timing Sequencer), source from other intputs
- DIN-35 Rail mountable
- LEDS indicate power, input activity, output activity
- Pins grouped in blocks of 12 signals, each block of 12 has its own connector
- Many different cabling options supported from frame grabber to BitBox
- Cables can be purchased from BitFlow or customer manufactured (simple connectors used through out)
- Power requirements 5 to 24 VDC
