Since 1993, BitFlow has been developing industrial frame grabbers and software specializing in interfacing to cameras with high data/frame rates; and running in applications where every CPU cycle is precious. We currently offer CXP, CL, and Differential frame grabbers.
Product filed under:
Frame Grabbers & Imaging Boards Frame Grabbers & Imaging Boards
- Camera Link 2.0 Compliant
- Supports up to two cameras
- Supports base, medium, full, 80-bit (10-tap) CL cameras
- Supports CL clocks up to 85 MHz
- Supports simultaneous capture from two 80-bit/85 MHz cameras
- Industry standard SDR Camera Link connectors
- Support PoCL and non-PoCL cameras
- Support dual connector PoCL
- Provides Safe Power, full protection from all power line faults
- Cameras can be accurately synchronized, or can be completely independent
- PCI Express x4 Gen 2.0 interface (also works in x8 and x16 slots)
- Compatible with PCI Express Gen 1.0 slots
- Separate I/O for each camera
- Highly deterministic, low latency frame grabber to camera trigger
- Supports simultaneous communications to all cameras
- Windows "sees" a separate frame grabber for each camera
- FlowThru technology means no on-board memory is needed
- StreamSync acquisition engine optimizes synchronization between acquisition and DMA
- StreamSync buffer manager maximize DMA channel efficiency
- Acquire variable length frames from line scan cameras
- Acquire image sequences well beyond the 4GB barrier
- No frame rate limit
- Triggers and encoders for external control of acquisition
- Programmable signal generator for camera control (independent for each camera)
- Quadrature encoder support including sophisticated triggering schemes
- Encoder divider/multiplier
- Drivers, utilities, and examples for Windows and Linux
- Supported on both 32-bit and 64-bit platforms
- Drivers for most 3rd party processing environments (e.g. HALCON, LabView, VisionPro, MATLAB, etc.)
- Full GenICam support for control and capture
- RoHS compliant
