FE060-5-CM

Model: FE060-5-CM

ADVANCED Motion Controls

Request a Quote

The FE060-5-CM FlexPro® pcb mount servo drive with IMPACT™ architecture offers full tuning control of all servo loops

Image of FE060-5-CM

The FE060-5-CM is a FlexPro® series servo drive with IMPACT™ architecture. The FE060-5-CM offers full tuning control of all servo loops and is designed to drive brushed and brushless servo motors, stepper motors, and AC induction motors. The drive accepts a variety of external command signals, or can use the built-in Motion Engine, an internal motion controller used with Sequencing and Indexing commands. Programmable digital and analog I/O are included to enhance interfacing with external controllers and devices. The FE060-5-CM features a CANopen interface for network communication and USB connectivity for drive configuration and setup. All drive and motor parameters are stored in non-volatile memory.

The FE060-5-CM is ideal for applications in the Military/Defense industry.

See the product detail page for the FE060-5-CM on the Advanced Motion Controls website.

Features





Inputs/Outputs

  • 4 Programmable Digital Inputs
  • 3 Programmable Digital Ouputs
  • 1 Programmable Analog Input

Network Communication

  • CANopen

Operating Modes

  • Profile Modes
  • Cyclic Synchronous Modes
  • Current
  • Velocity
  • Position
  • Interpolated Position Mode (PVT)

Primary Feedback

  • Absolute Encoder
    • BiSS C-Mode
    • EnDat 2.2
    • Tamagawa/Nikon
  • Incremental Encoder
  • Hall Sensors
  • Aux Incremental Encoder
  • Tachomoter (±10V)



Motor Types

  • Three Phase
  • Single Phase
  • Stepper
  • AC Induction

Control/Command

  • Over the Network
  • ±10V Analog
  • Sequencing
  • Indexing
  • Jogging
  • Step & Direction
  • Encoder Following
