Meet the New Ultra-compact Telecentric optics for up to 260 mm FOV

POSTED 05/13/2020

Smaller size, larger view! Meet the new ultra-compact telecentric optics for up to 260 mm FOV.The CORE PLUS family keeps growing: Opto Engineering® is proud to introduce the new ultra-compact telecentric lenses and collimated illuminators for up to 260 mm field of view.

Featuring a smaller footprint and lightweight design, the new additions to the CORE PLUS family will take your vision system to the next level.

Typical applications include measurement of tablet batteries and housings, high-precision gauging of large machined parts, microplate inspection and dimensional verification of large size bottles.

TC CORE PLUS series

Ultra-compact LARGE FOV bi-telecentric lenses for matrix detectors up to 2/3”

PN                               DESCRIPTION

TCCP12260               Ultra-compact bi-telecentric lens for matrix detectors up to 1/1.8”

                                     0.027x magnification

TCCP23260               Ultra-compact bi-telecentric lens for matrix detectors up to 2/3”

                                     0.036x magnification

TC3MHR-TC5MHR CORE PLUS series

Ultra-compact large FOV telecentric lenses for matrix detectors up to 4/3”

PN                                  DESCRIPTION

TCCP3MHR260-C       Ultra-compact bi-telecentric lens for matrix detectors up to 1.1”

                                        0.053x magnification

TCCP5MHR260-F        Ultra-compact bi-telecentric lens for matrix detectors up to 4/3”
                                        0.072x magnification

LTCLHP CORE PLUS series

Space-saving telecentric illuminators for large FOV systems

PN                                DESCRIPTION

LTCLCP260-G            Space-saving telecentric illuminator, 265mm x 200 mm beam area, green

Contact our sales engineers for more info!
