Xenics is a designer and manufacturer of infrared sensors, cores and cameras.
Product filed under:
Cameras & Smart Cameras, Image Sensors, and USB Cameras Cameras & Smart Cameras, Image Sensors, and USB Cameras
Ultra-compact thermal imaging camera
The Dione 1024 CAM series is based upon the Dione 1024 OEM thermal imaging core with 1024×768 pixels and 12 μm pixel pitch. The NETD is less than 40 mK (available upon request) or 50 mK. The maximum frame rate is 80 Hz.
Dione 1024 CAM is a LWIR uncooled thermal imaging SWaP module with housing supporting M34/M45 lens (optional).
Dione 1024 CAM series benefit from Xenics image enhancement for advanced image processing while keeping power consumption low. Moreover, GenICam compliance and the availability of multiple lenses (optional) provides a high level of tunability for optimal integration into many systems.
The compact Dione 1024 CAM series find applications in safety and security, transportation and industrial process monitoring.
Benefits and Features
• Ultra-compact size, low weight and power (SWaP)
• 1024×768 microbolometer detector with 12 μm pixel pitch
• Frame rates up to 80 Hz
• Detector NETD is less than 40 mK (available upon request) or 50 mK
• Uncooled and shutterless
For more information: DIONE | Exosens
