4-port 2.5GigE PoE+ Expansion Card

Model: PE-6004 (2.5G PoE+)

Vecow Co., Ltd.

Image of 4-port 2.5GigE PoE+ Expansion Card

- Intel® I225 2.5GBASE-T Ethernet Controller supports 4-port independent 2.5GigE LAN, up to 2.5Gbps data rate -PCI Express x4 interface, PCIe 3.0 supports up to 8.0 GT/s -Supports IEEE 802.3at Power over Ethernet (PoE+), up to 25.5W Power Output at 48V DC per port, with PoE+ On/Off Control -IEEE 802.3bz (2500BASE-T), IEEE 802.3ab (1000BASE-T), IEEE 802.3u (100BASE-TX), and IEEE 802.3i (10BASE-TX) compliant -Teaming features : Fault Tolerance, IEEE 802.3ad Link Aggregation and Load Balancing, up to 9KB Jumbo Frame - Time Sensitive Network (TSN) features : IEEE 1588 Precision Time Protocol (PTP), IEEE 802.3AS Precision Timing Synchronization, IEEE 802.1Qav and 802.1Qbv -Supports IEEE 802.3az Energy Efficient Ethernet (EEE) and DMA Coalescing Power Management features -Integrated Switching Voltage Regulator (iSVR) and IEEE 802.1q VLAN supported - -25°C to 60°C Operating Temperature
