Iron Core Motors

Designed and constructed with an iron core, these linear motors offer extremely high continuous force for their size, starting at 60N for the small TM, all the way up to 3000N for the water cooled TBW powerhouse. Peak forces are even higher, reaching up to 6000N.

All this raw power comes in a surprisingly compact package. Its small footprint, modular design and high force density enable very fleible application designs. The ability to string multiple motors together, either in series or parallel, widens its range of applications even further.

TL SERIES - FP 400..3200N FC 200..1600N

The mid-range TL is our most popular iron core motor. It features an extremely low attraction force between the coils and the magnets and stands out for its small size, high acceleration, high speed and accuracy. The TL is also available in long versions, which makes this all-rounder suited for nearly any application, including those with long travel lengths, like printers for large digital formats.

Coil Units: TL6 - TL9 - TL12 - TL18 - TL24
Magnet Plates: TL192 - TL28

A small footprint, modular design, and high force density enable very flexible application designs, using iron core linear motors. The ability to string multiple motors together, either in series or parallel, widens its range of applications even further.

Advantages of iron core linear motors

• High force density and more force in a smaller packing mean lowering footprint and fitting better in small spaces.
• Low cogging, optimized iron core motor design, for smooth motion and position accuracy in your application.
• Approved for CSA and CE, ROHS, they are approved for CE, CSA, and ROHS.
• Aluminum housed design with integrated water cooling for TBW- and TL series.

Check the key applications that can benefit from linear motors, such as printing, digital cutting, and machine tooling.
