TX2-40 ESD (ElectroStatic Discharge) 6-axis robot
Model: TX2-40 ESD (ElectroStatic Discharge) 6-axis robot
The ESD line of robots is designed to prevent ElectroStatic Discharges and comes in 6-axis versions in various sizes with reaches ranging from 515 to 2,594 mm. These super high performance robots deliver the perfect level of speed, precision and reliability for handling electronic components.
Advantages of the TX2-40 ESD
ESD compliance guaranteed by 3 specific tests
- surface resistivity
- residual charges
- dissipation and transversal conductivity
7 test points covering every arm’s element
Minimize part failures and rework costs
Ensure that all accessible elements are dissipative to eliminate ESD risks in production. Specific ESD compliant paint
Safely handle sensitive devices
Each arm link connected to ground, transversal conductivity
Flexible integration on the production line
For greater flexibility, Stäubli robots have multiple mounting configurations (floor, wall or ceiling) to make it easier to integrate the robot into the production chain.
Optimum cleanliness, arm motion freedom and production reliability
- All cables and pipes routed through the arm removing obstacles from the work area
- Enclosed structure
Optimum use of the work area
- Less floorspace needed
- Large work envelope
Eliminating complex cable management
- Connections directly on the robot forearm thanks to integrated electrical and Ethernet cables
Work in difficult environments
- Vertical cable outlet, complete protection of connections
- Specific joints
Precise trajectory performance
- Increased part quality
- Reduced rework costs
- Rigid structure
High precision, long life time and reduced maintenance
- JCS gearbox designed by Stäubli
Certifications
- UL, CE, KCS
