SD33-600 Long-Range Laser Displacement Sensor – 600 mm Standoff, 800 mm Measurement Span

Discover the SinceVision SD33-600 Long-Range Laser Displacement Sensor with a 600 mm reference distance and a ±400 mm measurement range. Ideal for precise, non-contact height and distance checks on large parts in lithium battery, automotive, and consumer electronics manufacturing.

The SD33-600 places you far from the target surface, giving you an 800 mm total measurement span while standing up to 1000 mm away. This generous clearance helps you inspect big castings, structural body panels, and wide battery trays without risk of collision. The sensor uses laser triangulation and handles high-duty production environments with steady, repeatable performance.

Key Features:

• Reference distance: 600 mm – mounts in safe zones away from robots, clamps, and moving fixtures
• Measurement range: ±400 mm – an 800 mm window captures height variation across oversized parts in one view, minimising sensor repositioning
• Linearity: ±0.25% of Full Scale – delivers precise flatness, step height, and runout results across the full measurement span
• Spot size: 1600 μm – a larger measurement spot smooths over textured or rough surfaces for stable readings on cast and stamped components
• Laser output power: 1 mW – eye-safe design for open manufacturing cells
• Sampling frequency: selectable from 100 Hz to 3000 Hz – match the speed of fast-moving lines or choose lower rates for high-accuracy static checks

Engineered for long-term stability, the SD33-600 laser displacement sensor provides a reliable non-contact distance measurement solution that integrates smoothly into automated inspection and guidance systems.

For more details, click here SD33-600
