Shenzhen SinceVision Technology Co. Ltd. Product

SD33-195 Laser Displacement Sensor

Model: SD33-195

Shenzhen SinceVision Technology Co. Ltd.

The SinceVision SD33-195 laser displacement sensor offers high-precision (50µm) and high-speed (3000Hz) measurement in a compact, integrated design. Ideal for industrial automation. Learn more!

Image of SD33-195 Laser Displacement Sensor

The SinceVision SD33-195 laser displacement sensor offers high-precision, non-contact measurement in a compact, integrated body. Its simple setup and robust design make it ideal for a wide range of industrial automation applications. Featuring glass lenses for the light outlet and receiving area, the SD33-195 provides superior temperature resistance, light transmission, and corrosion resistance for reliable performance in demanding environments.

Key Features:

  • Reference Distance (CD): 195mm
  • Repetition Accuracy: 50μm
  • Sampling Frequency: Up to 3000Hz
  • Linearity: ±0.1% F.S.
  • Integrated Design: Compact and easy to integrate into various systems.
  • Durable Construction: Glass lenses provide excellent temperature and corrosion resistance.
  • High-Speed Measurement: Up to 3000Hz sampling frequency for real-time data acquisition.
  • Precise and Reliable: 50μm repetition accuracy and ±0.1% F.S. linearity ensure accurate and consistent measurements.

For more details, click here SinceVision



Contact Us:

Email: [email protected]

Website: www.sincevision.com

Automotive Component Dimensional Inspection with SinceVision SD33 Laser Displacement Sensor
