Schmersal designs and manufactures UL, CSA and CE-compliant machine guarding safety components including keyed interlock switches, keyed interlock switches with solenoid-locking, hinged safety interlock switches, non-contact safety sensors, coded-magnet sensors, emergency cable-pull switches, safety-rated limit switches, safety edges, safety light beams and light curtains, laser scanners, safety pressure mats, and safety controllers, and configurable safety controllers. All Schmersal safety products are third-party certified to the relevant directives and standards. In addition the firm offers free in-house safety training seminars, safety videos, and tutorial handbooks on machine safeguarding.
Product filed under:
Safety Products Safety Products
The TESF Series is designed for use with hinged machine guards which must be closed for operator safety. Their tamper-resistant design and positive-opening NC contacts provide a significantly higher level of safety than conventional, spring-driven limit switches or proximity switches often used to monitor hinged guard positions.
Their compact, low-profile design and IP65 rating make them ideal for interlocking hinged safety guards in industrial environments. Designed to mount directly on the hinged guard and its stationary frame, it is easy to install on a wide range of extruded aluminum guard sizes and other guard styles.
Among its unique features is its ability to adjust the switching point in the field to meet specific application requirements. Once adjusted, the switching point is easily permanently locked to prevent further adjustment by unauthorized personnel. In addition, it features top or bottom cable entries, 1 NO or 2 NO and 2 NC contacts, designs suitable for inside or outside-guard mounting, and the ability to open a full 180°.
