WCO-3000-EHL Advanced IP68/69K Waterproof Computer With Intel Atom® X6425E CPU, 1x DP, 2x LAN, 2x USB 3.2 Gen 2

• Support Intel Atom® x6425E Processor
• 1x 260-pin DDR4 SODIMM. Max up to 32GB
• Single display supported by 1x Real 4K DisplayPort
• 2x LAN by M12 X-Code (2.5GbE and 1GbE)
• 1x RS-232/422/485 by M12 A-Code, 2x USB 3.2 Gen 2 (waterproof connector)
• 1x 2.5" SATA HDD bay and 1x mSATA (shared by 1x Mini PCIe)
• 1x Full-size mini PCIe for communication or expansion modules, 2x Internal SIM socket
• Full system IP68/69K level dustproof & waterproof
• 9 to 36VDC / 48 to 110VDC wide range power input supporting AT/ATX mode
• -40°C to 60°C extended operating temperature
• TPM 2.0 Supported
• Edge AI Ready with Hailo-8™ (26 TOPS / 2.5W)

Built Rugged, Built Ready

The WCO-3000-EHL Series is built to withstand harsh environments while maintaining high performance and industrial-grade reliability.

• Wide Temperature Range: -40°C to 60°C
• 50G Shock & 5Grms Vibration (MIL-STD-810G Compliance)
• Wide Voltage Input: 9VDC-36VDC Input
• CE, FCC Safety Certifications

IP68 & IP69K Dust And Water Protection

The WCO-3000-EHL can support IP68 and IP69K ratings.

• IP68: Protected against full water immersion beyond 1m up to 30 mins (More suitable for devices used in water-related activities.)
• IP69K: Totally dust-tight and be protected against high-temperature, high-pressure water jet sprays

High-Speed I/O Ports And 4K Display

The WCO-3000-EHL supports high-speed I/O ports with M12 connectors for more demanding IIoT edge applications.

• 1x 2.5Gb Ethernet for low-latency real-time connectivity
• 2x USB 3.2 Gen 2 (10 Gbps) for improved data transfer rate
• 1x True 4K Dual Independent DisplayPort

Edge AI Ready With Hailo AI Acceleration

WCO-3000-EHL is compatible with a small form factor, power-efficient Hailo-8™ AI acceleration module to deliver high-performance real-time AI processing with low power consumption.

• Up to 26 TOPS
• Low-power efficiency (2.5W)

Mobile IoT Connectivity Ready

WCO-3000-EHL features a Dual-SIM socket compatible with 5G cellular connectivity through a modular add-in card.

• 5G/4G LTE support with major North America cellular carriers like AT&T, T-Mobile, and Verizon
• Supports Multiple SIM Cards
• Wi-Fi, and Bluetooth

Intelligent Transportation Ready

The WCO Series implements essential on-board I/O specific for automation and transportation deployment applications.

• Optional CAN Bus headers for communication with other modules and network devices
• Optional Power Ignition Management for ignition sensing and management
