The Piab journey started 70 years ago by developing progressive solutions for gripping, lifting and moving. More than 65 patents and countless innovations later it is clear that we always strive to improve for the better. This year is all about celebrating our quest of evolving automation – in a lot of different ways. Stay tuned!
Product filed under:
End of Arm Tooling and Grippers End of Arm Tooling and Grippers
A new smaller version of their Internal Diameter Gripper (IDG) 16-26-33 ideal for parts that are small, fragile, or have an irregular shape. The IDG grips and releases on command and is highly recommended for manipulating breakable parts. Unlike standard clamps, the IDG distributes force evenly over the entire contact area which is why they are most often used for irregular shaped parts. This new IDG is a cost effective solution when compared to bladder grippers and automated or magnetic clamps.
Significant Features:
- Secures ID’s ranging from 26-33mm.
- Requires one compressed air line; spring return
- Extremely strong for its size -- jaws exert 14 lbs force @ 90 PSI.
- Ø1/8” Neoprene rubber cord stock inserts ensure a secure grip – and can be replaced at low cost. Other elastomers can be used and are commercially available.
- Nose adapter can easily be customized for locating or part stabilization.
