POST STAND - Compact and Modular Microscope Stand
Model: Long Working Distance Microscope Stand
Economical, Ergonomic, Flexible, and Reliable - Opto's Post Stand, a compact and modular microscope stand for precise measurement and microscopic analysis
Our 32mm-column system is the most popular of our microscope stands and for many years in Opto's product family.
Many thousand units produced and delivered stand for highest quality, reliabilit, and economic support for your instruments. It is configurable for almost all applications. For configuration possibilities refer to the datasheet /catalog.
Technical Features:
Clamp diameter: 35mm
Vertical travel of Focus Drive C : 57mm
Stand height: 510mm
Column diameter: 32mm
Travel range of manual stage: 75mm x 55mm
Alu plate dimension: 300 x 300 x 12
Accessories:
100-JC2-66 Jointed Couplers, 2 left, M6-M6, L=132mm
Documentation: http://www.opto.de/media/post_stand_datasheet_en.web.pdf
