OPTICS - IMAGING - AUTOMATION Opto manufacturers unique Compact embedded Imaging Modules with on board Camera/Lens/Light/Intelligence as one unit with one wire, ´plug and play` to machine builders and OEMs for industrial and biomedical applications. Opto reduces all solutions to their needs in Size, Weight, Price to add maximized Value for the Photonic and Machine Vision Markets.
Product filed under:
Motors & Drives Motors & Drives
Focus Drive OC, Coarse | Fine For objectives with magnification up to 50x. One combined focus drive for coarse and fine alignment. Scale on knob with 100 sections. Technical Features: Travel range: Coarse focus 80mm (+42/-38mm) Travel per knob rotation: Fine focus 0.24mm (288° rotation) Fine focus mode is active after a direction change in coarse and stays active within 288° Scale on knob: 100 sections - 1 section matches 2.9µm in fine focus For objectives up to 50x Dimensions: 50 x 99 x 125mm Weight approx. 1,2kg Load max. 15kg Article number 043-610022
