Midwest Optical Systems, headquartered in Palatine, IL, has more than 30 years of experience and innovation in optical design, fabrication and inspection. MidOpt is a worldwide leader in machine vision filters and optical solutions and is represented in over 30 countries, offers over 3,000 cutting-edge products and ships over 100,000 filters yearly. MidOpt filters are the premier solution for industrial imaging to ensure flawless control, dependable results and the best image quality. Every filter is produced with the highest standards in durability to withstand even the harshest environments. Unlike traditional filters, MidOpt filters are designed to allow maximum transmission, emulate the output of the most common LED wavelengths and are less angular dependent. Industries served: -Machine Vision/Factory Automation -Security & Surveillance -License Plate Recognition/ITS -Medical & Life Science -Agricultural Inspection -Aerial Imaging -Motion Analysis -Photography & Cinematography
Product filed under:
Optics / Lenses / Filters Optics / Lenses / Filters
Polarizers are designed to reduce specular glare by passing only the light polarized in the direction perpendicular to the reflected light (glare). They also help improve contrast, increase color saturation and detect imperfections in transparent materials. MidOpt Polarizing Filters can be easily and securely mounted to your lens and light source for maximum extinction or glare reduction.
POLARIZING FILTERS
Contrast ratio of up to 6500:1
Linear, circular and wire grid polarizers are available for VIS and NIR spectrums
Rotating mount with locking thumb screw to fine tune glare reduction
Exceptional surface quality: 40/20 scratch/dig
POLARIZING FILM
Achieves optimal glare reduction when placed over light source
Contrast ratios of up to 10000:1
Linear polarizers are available for VIS and NIR requirements
Left and right circular polarizers are available for VIS spectrum applications
Offered in high-temperature-resistant laminate and glass
PSA007 material comes standard with self-adhesive backing
MOUNT AND SIZE OPTIONS: Polarizing Filters and Films are in-stock and ready-to-ship. Polarizing Filters are available in threaded mounts, sizes M22.5 to M105;?slip mounts; or unmounted. Polarizing Films are available in multiple thicknesses and can be custom laser cut to t any light source with a maximum usable width of 16.5” and length up to 300’.
APPLICATIONS: Polarizers are commonly used to reduce glare from non-metallic in objects with smooth surfaces or surfaces covered with grease, oil or liquid. For best results, use an optical-grade Polarizer over the lens and Polarizing Film over the light source. The PR120/PG120 offers ultra-high contrast and an anti-reflection oleophobic coating.
