ML6 Polyurethane Coated Cam Followers

• Manufactured using high-quality, American made cam followers.
• Tight tolerances and low runout guaranteed with the precision molding process.
• Provides protection of product or track surfaces from wear and tear, while also reducing noise.
• Unbeatable bond strength between ML6 polyurethane and core materials.

Polyurethane covered cam followers, also known as track rollers, are designed to guide materials and support movable assemblies while protecting surfaces they come in contact with, such as expensive track equipment, while also reducing noise. They are mounted using the threaded stud installed into a tapped hole or by installing into a through hole and securing in place with a nut. The threaded studs feature a re-lubrication hole where a grease zerk can be installed or the hole can be plugged with the included brass insert.

Polyurethane molded cam followers are used in a wide range of industrial and automation applications, typically where higher load bearing is required. They are available in a wide variety of different durometers, styles, sizes, and options.

Standard ML6 polyurethane molded track rollers are made from black-oxide coated steel but are available in stainless steel upon request, in both SAE and Metric sizes.

Custom ML6 polyurethane covered cam followers are available affordably, with quick turnaround times if your application requires a different polyurethane thickness, molded profile, or other changes to the design. Meridian Laboratory specializes in delivering high-quality, precision custom ML6 polyurethane molded cam followers – ranging in quantities from 1 to 1M+.  Click here to learn more about our custom ML6 polyurethane molding process.

All ML6 polyurethane coated cam followers are manufactured with Meridian Laboratory’s ML6 polyurethane bonded directly to the outer bearing race, done so in a way that prevents tear-off and provides excellent longevity.

Meridian Laboratory’s process for molding precision ML6 polyurethane covered cam followers ensures exceptional tolerances and total indicated runout as low as 0.0015”, far tighter than other manufacturers.
