High Precision ToF Camera Featuring Sony DepthSense

The “gold” award-winning Helios is a compact, high precision, industrial 3D camera that integrates Sony’s DepthSense™ IMX556PLR back-illuminated ToF image sensor. The camera delivers 640 x 480 depth resolution at a 6m working distance using four 850nm VCSEL laser diodes. On-camera processing provides range, intensity and confidence data which reduces the need for expensive host system components. A robust design with an M12 Ethernet connector and up to 100m cable length makes the camera ideal for a variety of factory and warehouse environments.

• Superior depth precision compared to existing ToF solutions on the market
• Industrial robustness with M12 connector, up to 100m Ethernet cable distance
• On camera depth processing lowers host system usage
• Excellent price performance

Its compact form factor, industrial reliability and attractive price point enables many 3D applications such as 3D inspection, automated material handling and robotics to run more efficiently while reducing overall system cost.

LUCID’s own Arena SDK includes easy to use controls for the Helios ToF camera. The ArenaView GUI can show the intensity and depth of a scene in either a 2D view or a 3D point cloud view, which can be manipulated and oriented in real-time. Additionally, settings can be adjusted and seen in real-time, including false color overlay and depth range.

Unlock the potential of Time of Flight in a variety of industrial applications including robotic navigation, 3D inspection and logistic automation.
