LAPP’s ÖLFLEX®, ETHERLINE®, and UNITRONIC® continuous flexing cables play an integral role in high-speed robotics applications, such as multi-axis articulated arm, Cartesian and SCARA robots. At LAPP, we design and manufacture a full range of high-flex, high-torsion, abrasion resistant cables, connector and cable tracks for static, dynamic and torsional robots that can reliably transmit power, control, data, and monitoring signals— while withstanding repetitive movements, extreme twisting and bending. As one of the world’s premier robotic cable carriers, we offer a wide range of connectivity solutions for demanding robotics applications. High-flex cables for static, dynamic and torsional robots - High-torsion Ethernet cables - Continuous-flex (FD) cables and cable chain - Custom ÖLFLEX® CONNECT assemblies - Non-metallic cable glands for fast assembly and reliable connections - Circular and rectangular connectors - Abrasion-resistant, continuous-flex conduits.
Product filed under:
Cables, Enclosures & Ancillary Products, and Controls Cables, Enclosures & Ancillary Products, Controls, End of Arm Tooling, Industrial, Robots, and Turnkey Systems & Components and Specialized Tooling
See More
ÖLFLEX® VFD SLIM: Reduced-Diameter VFD Cable; 600V/1000V; UL & cUL TC Approval
Model: ÖLFLEX® VFD SLIM
ÖLFLEX® VFD SLIM is a reduced-diameter shielded motor cable for VFD drives. It is designed with the “Lapp Surge Guard” insulation system, which includes a semiconductive layer made to withstand nonlinear power distortions associated with VFD drives and to disperse increases in voltage caused by wave reflection, spikes, in-rush current, and harmonics.
Recommended Applications
VFD drive and motor applications; web presses; HVAC; conveyors; any on/off, slow down/speed up applications using VFD drives and motors
Application Advantages:
- “Lapp Surge Guard” insulation protection
- UL TC-ER & c(UL) CIC/TC approved
- Double shielded for extra protection
Construction:
- Conductors: Finely stranded tinned copper
- Insulation: "Lapp Surge Guard" insulation system
- Shielding: Barrier tape; triple layer foil tape (100% coverage); tinned copper braid (85% coverage)
- Jacket: Specially formulated thermoplastic polymer; black
Approvals
UL:
- TC-ER per UL 1277
- MTW per UL 1063
- WTTC per UL 2277
- AWM 20886
Attributes:
- UL Oil Res I/II
- 75°C Wet; 90°C Dry
- -40°C Cold Bend; -25°C Cold Impact
- Sunlight resistant
- Direct burial
- Submersible Pump (14 AWG & larger)
- NFPA 79 2015
NEC:
- Class 1 Division 2 per NEC Articles 336, 501
Canada:
- c(UL) CIC/TC FT4
- CSA AWM I/II A/B 1000V FT4
Additional:
- MSHA P-07KA050013-MSHA
- CE & RoHS
