Integrated Design Tools (“IDT”) was founded in 1997 to design and develop digital video cameras with high framing rate capabilities. Since 1997 a number of innovative designs were conceived that included integration of various methods to transfer image/control data to and from the cameras with a variety of of-the-shelf equipment such as computers, video recorders as well as digital video recorders designed by IDT. IDT’s cameras are offered in a variety of miniature packages designed to serve broad scientific, industrial and media applications as evidenced in our web site. Notable examples are the cameras used in space and airborne platforms, automotive safety testing, media and cine and industrial inspection.
Product filed under:
Cameras & Smart Cameras Cameras & Smart Cameras
IDT’s CrashCam mini (CCM)1550 and 3525 cameras provide high-speed image capture in a shockproof, ultra-compact design. Supporting 8GB DDR RAM and up to 256 GB removable Micro SD for image storage, these cameras are ideal for quick troubleshooting of fast events – especially in harsh and space-limited environments. Thanks to its unique operating system and HD SDI output capability, the CCM series can deliver live video streams, while also recording at high frames rates (configurable up to 960 fps) into internal memory. This memory can be configured to initiate live, high definition PLAYBACK. All camera operations and settings are controlled with the ease-of-use of your smartphone via IDT’s MotionPad™ application, available in the iOS and Android OS environments.
FEATURES- Ultra-compact form factor
- HD SDI output
- Micro SD compatible
POWER: Input voltage 7-12 VDC
OPTICAL INTERFACE: C-mount standard
COMMUNICATION INTERFACE
- Gigabit Ethernet (1000BaseT)
- 3G HD SDI
TRIGGERING AND SYNCHRONIZATION
- TTL and switch closure trigger
- Circular buffer with trigger
- On camera (motion) and software trigger
- IEEE1588, 1 PPS, & TTL Synchronization
Image Capacity
- DDR: 8GB (Standard)
- Removable Micro SD up to 256 GB
| Frame Properties | Model 1550 | Model 3525 |
| Max Resolution | 1440 x1024 pixels | 2560 x 1440 pixels |
| Max Rate | 5,000 fps | 2,500 fps |
