GMSL2 3MP Fixed Focus Camera Module

Features

• GMSL2™ interface, max resolution 3MP @60fps
• Lens FOV (D / H / V): 80° / 64° / 41°
• Supports HDR, LFM, Integrated Image Signal Processor (ISP), and IP69K Housing
• Dynamic Range: 120dB
• Complies with CE / FCC Class A
• Platform Support: NVIDIA Jetson Orin

Designed for long-distance vision applications, Innodisk’s GMSL2™ 3MP Fixed Focus Camera Module delivers low-latency image transmission across distances of up to 15 meters. Encased in an IP69K-rated rugged housing, it ensures reliable performance in harsh outdoor or on-the-move environments. Equipped with HDR (High Dynamic Range) and LFM (LED Flicker Mitigation) features, the EV3F-ZSM1-RXCF enhances image clarity and stability under extreme lighting conditions. Fully compatible with NVIDIA Jetson Orin, the camera integrates all these strengths to provide an ideal vision solution for mobility, robotics, and industrial applications.

HDR FOR SUPERIOR IMAGE CLARITY

Innodisk's GMSL2™ Camera Module features cutting-edge HDR (High Dynamic Range) technology, ensuring exceptional image clarity and sharpness even in challenging lighting conditions. By effectively extending the dynamic range, HDR technology captures intricate shadow details and vivid highlights, delivering images with unparalleled realism and natural balance.

LFM FOR STABLE IMAGING UNDER LED LIGHTING

Featuring LFM (LED Flicker Mitigation), the EV3F-ZSM1-RXCF delivers stable imaging under both artificial and LED lighting. By optimizing exposure timing, the camera minimizes flicker caused by LED pulse illumination, while the Sony ISX031 sensor provides precise brightness control to prevent pixel saturation or blowout, producing clear, flicker-free images.

HIGHEST RATING IP69K FOR OUTDOOR SCENARIOS

Built for harsh outdoor environments, Innodisk’s EV3F-ZSM1-RXCF offers the highest IP69K-rated protection against dust, water, and high-pressure cleaning. This ensures stable operation in demanding conditions, making it ideal for heavy machinery, outdoor factories, and other challenging industrial environments.

ADD-ON ADAPTER BOARD FOR EASY INTEGRATION

To simplify system design and reduce deployment costs, Innodisk offers a range of customizable adapter boards for seamless connection with NVIDIA Jetson Orin platforms. Leveraging the added value of the adapter board, developers and system integrators can accelerate validation, shorten time-to-market, and ensure stable, high-speed data transmission in multi-camera applications.
