APEX-P200 Edge AI System

Intel-Based AI System with NVIDIA RTX 2000 Ada Accelerator

• MXM Type A with 3,072 CUDA Cores, 96 Tensor Cores, and 24 RT Cores
• 64GB DDR5 and 512GB NVMe SSD pre-installed
• Compact design: 182mm x 158.6mm x 90mm

The APEX-P200 features a compact design with high processing power, making it ideal for complex tasks such as medical image analysis, AGV/AMR, AI object detection, and AI behavior analysis.

HIGH-PROCESSING POWER

The APEX-P200, powered by NVIDIA's latest Ada Lovelace architecture RTX 2000 accelerator, features 3,072 CUDA Cores, 96 Tensor Cores, and 24 RT Cores, making it ideal for the demanding requirements of localized AI inference and complex AI tasks.

COMPACT AND POWERFUL DESIGN

The compact APEX-P200 (182mm x 158.6mm x 90mm), one of the smallest edge AI systems compatible with MXM Type A, is ideal for space-constrained applications. It supports a wide temperature range of -20 to 60 degrees, making it suitable for outdoor and demanding environments.

DIVERSE I/O PORT OPTIONS

3 x 2.5G RJ45 LAN Ports, with two ports providing up to 30W PoE. OOB port enables out-of-band management, allowing system operators to manage and maintain edge devices even if the operating system fails.

VERSATILE AND COMPATIBLE COMPONENT OPTIONS

In addition to the pre-installed options, Innodisk offers flexible selections from our complete range of industrial-grade SSDs, DRAM modules, and embedded peripherals, all available for customization to meet specific needs.

HIGHLY CUSTOMIZED SERVICES

We provide customized AI system services with a flexible collaboration approach. While the included AI accelerator is the recommended option, we also offer a range of alternatives to meet specific requirements. Additionally, hardware, software, thermal solutions, firmware, BIOS, I/O, and system design can all be tailored to your exact needs.
