DOLD 3 Stage Enabling Switch RE 6909

Model: DOLD RE 6909

Industrial Safety Controls Inc

The enabling switch allows Maintenace Personnel to enable machine functions such as jog, stop or reverse inside a guarded area

Image of DOLD 3 Stage Enabling Switch RE 6909

Product description

The enabling switch serves as an enabling device acc. EN 60204-1 and meets the requirements for enabling devices with three positions as determined in EN 60947-5-8.

The enabling switch features two normally open contacts controlling the safety function. When the enabling switch is activated both contacts are closed and the plant is released. If the enabling switch is pushed through resp. released the safety function is triggered and both contacts open up.

Only evaluation units with cross-circuit monitoring may be used.

Technical specifications

Width: 53 mm
Type: RE 6909



Advantages

  • Safe working in hazardous areas
  • Ergonomic design and fatigue-free working
  • Expandable and applicable in many ways
  • Safe during set-up-mode
  • Safety during maintenance of machines and installations

Features

  • Modular set-up
  • Enabling switch
  • E-Stop button (optional)
  • Operating unit
  • Additional function keys, expandable e.g. for control functions (optional)
  • Universal attachment of holders via M4 and/or UNC #4-40 thread
